Siemens 1FK7034-2AK71-1CG0
€1,650.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Documented identifiers and values: MXG461.25-8.0; MXG461; 25; 16; 24 V; 50/60; 10 V; 10 V; 20; 10 V; 50. Adjacent MXG461 variants differ in connection size and flow capacity and are not generally interchangeable. The valve is documented for water and water/glycol mixtures containing up to 50 percent glycol. With nominal size DN 25, pressure rating PN 16 and a Kvs value of 8 m³/h, the valve covers typical tasks in building services and industrial media control. The magnetic actuator accepts selectable DC 0–10 V, DC 2–10 V or 4–20 mA control signals and also provides a position feedback signal. Siemens MXG461.25-8.0 is a modulating control valve from the Acvatix range with a directly integrated magnetic actuator. The assembly is factory matched as a valve-and-actuator unit and should therefore be replaced as a complete unit. The information covers device classification, configuration details, electrical data, interfaces and mechanical attributes where listed. This industrial component is described by its product identification and listed technical characteristics. The product data identifies the documented component variant and its listed technical characteristics. The Siemens dimensional drawing documents a body length of 110 mm, an overall height of 270 mm and a maximum housing width of 100 mm. The environmental declaration gives a product weight of 3.62 kg for MXG461.25-8.0. These mechanical data support installation, handling, storage and transport planning.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | Acvatix MXG461 |
| Manufacturer/order/identification number | MXG461.25-8.0 |
| Device type | Modulating threaded control valve with magnetic actuator |
| Connection size | DN 25 |
| Pressure rating | PN 16 |
| Flow coefficient | Kvs 8 m³/h |
| Supply voltage | 24 V AC, 50/60 Hz |
| Control signals | DC 0–10 V, DC 2–10 V or 4–20 mA |
| Position feedback | DC 0–10 V, load resistance > 500 Ω |
| Permitted media | Water or water/glycol mixtures with up to 50 % glycol |
| Application | Mixing or straight-through control in closed circuits |
| Operation | Mechanical manual control with AUTO, MANUAL and OFF |
| Diagnostic indication | Two-colour LED for operation, calibration and faults |
| Leakage rate A → AB | max. 0.02 % of Cv at 1 bar differential pressure |
| Dimensions | 110 × 270 × 100 mm (L × H × F) |
| Weight | 3.62 kg |
Related products
Go to shop
Siemens 6AV2 124-0UC02-0AX1
€5,080.00
Siemens 6ES7 314-6CH04-0AB0
€1,160.00
Siemens 6ES7513-1AL02-0AB0
€1,680.00
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the dimensions and weight of Siemens MXG461.25-8.0?
The control valve measures 110 × 270 × 100 mm in the Siemens drawing order L × H × F. The environmental declaration gives a product weight of 3.62 kg.
Which connection and signal data are documented?
The documented data are DN 25, PN 16, Kvs 8 m³/h and DC 0–10 V, DC 2–10 V or 4–20 mA control signals.
