Product description
ABB AF26Z-30-00-21 is a three-pole contactor from the AF-Z range for motor and industrial power circuits. ABB order number 1SBL236001R2100 identifies the version with three normally open main contacts and no integrated auxiliary contacts. For AC-1, the documentation specifies a rated operational current of 45 A. In AC-3 duty, motor power is listed as 11 kW at 400 V. The electronic wide-range coil accepts 24–60 V AC at 50/60 Hz or 20–60 V DC. ABB lists 16 W for pick-up and 1.7 W for holding. Screw terminals provide the electrical connection technology. Integrated surge suppression limits switching peaks at the coil. The product family is documented for power circuits up to 690 V AC and up to 220 V DC. Front- and side-mounted auxiliary contact blocks form part of the accessory concept for the compact block design. For mechanical planning, the exact ABB catalogue record gives a product width of 45 mm, a product height of 86 mm and a product depth of 86 mm. In the consistent width × height × depth order, complete external dimensions are therefore 45 × 86 × 86 mm. The corresponding net weight is 0.35 kg. These values refer to the individual contactor without additional auxiliary contact blocks, overload relay or packaging. Type number, ABB order number, contact configuration, coil range, ratings and enclosure dimensions clearly distinguish this version within the AF-Z range. The specification table concludes with Dimensions and Weight.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | ABB |
|---|---|
| Product series | AF-Z |
| Manufacturer / order / identification number | AF26Z-30-00-21 |
| Device type | Contactor |
| Number of poles | 3-pole |
| Main contacts | 3 normally open |
| Integrated auxiliary contacts | None |
| Rated operational current AC-1 | 45 A |
| Motor power AC-3 | 11 kW at 400 V |
| AC coil voltage | 24–60 V AC, 50/60 Hz |
| DC coil voltage | 20–60 V DC |
| Coil technology | Electronic wide-range coil |
| Pick-up power | 16 W |
| Holding power | 1.7 W |
| Connection technology | Screw terminals |
| Coil suppression | Integrated surge suppression |
| AC power circuits | Up to 690 V AC |
| DC power circuits | Up to 220 V DC |
| Dimensions | 45 × 86 × 86 mm (W × H × D) |
| Weight | 0.35 kg |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the external dimensions of ABB AF26Z-30-00-21?
Complete external dimensions are 45 × 86 × 86 mm in width × height × depth order.
How much does ABB AF26Z-30-00-21 weigh?
ABB specifies a net weight of 0.35 kg for order number 1SBL236001R2100.
