ABB 81AB03B-E
€790.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
With a width of 200 mm, a height of 99 mm and a depth of 85 mm, the B&R X20CP3686X controller accommodates three slots for additional X20 interface modules. The weight is 530 g, measured with battery and the X20TB12 terminal block. The CompactFlash card, slot covers and right end plate are not included in this weight. As the CPU of the X20 system, this version operates with an Atom processor at 1.3 GHz. The memory comprises 1 GB of LPDDR4-SDRAM, 1 MB of SRAM and 2 GB of eMMC flash. The usable share of the SRAM depends on the retentive variables configured in Automation Studio. For an order of the X20CP3686X with shipping from Germany to the United States and other international destinations, the complete type designation remains decisive for this processor and memory version. Cooling is fanless. Horizontal and vertical mounting orientations are provided; the permissible operating temperatures differ between them. Horizontally the range is −25 to 60 °C, vertically −25 to 50 °C, in each case taking derating into account. For the X2X Link supply, a reduction of the nominal output power to 5 W is provided above 55 °C. The degree of protection is IP20. The CPU and X2X Link are supplied with 24 V DC at a permissible tolerance of −20 to +25 %. Ethernet provides a shielded RJ45 connector with 10, 100 or 1000 Mbit/s. POWERLINK uses a further RJ45 connector and operates at 100 Mbit/s. The serial RS232 connection is made via the X20TB12 terminal block. Two USB-1.1/2.0 ports are designed as type A; for removable application memory, the controller has a CompactFlash slot.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | B&R Industrial Automation |
|---|---|
| Product series | X20 |
| Manufacturer/order/ident number | X20CP3686X |
| Device type | X20-SPS controller (PLC) |
| Processor | Atom, 1.3 GHz |
| Main memory | 1 GB LPDDR4-SDRAM |
| SRAM | 1 MB; usable share minus configured retentive variables |
| Internal application memory | 2 GB eMMC flash |
| Interface module slots | 3 |
| Ethernet | 1 × shielded RJ45, 10/100/1000 Mbit/s |
| POWERLINK | 1 × shielded RJ45, 100 Mbit/s, V2 |
| USB | 2 × USB 1.1/2.0, type A, maximum 0.5 A per port |
| RS232 | Via 12-pin terminal block X20TB12, maximum 115.2 kbit/s |
| CPU-/X2X Link supply | 24 V DC, −20 % / +25 %; maximum 1.5 A at 24 V DC |
| Cooling | Fanless |
| Degree of protection | IP20 according to EN 60529 |
| Operating temperature | Horizontal −25 to 60 °C, vertical −25 to 50 °C; observe derating |
| Dimensions | 200 × 99 × 85 mm (W × H × D) |
| Weight (reference basis not specified) | 0.53 kg |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
Which network interfaces does the X20CP3686X have?
The controller has an Ethernet interface with 10/100/1000 Mbit/s and a POWERLINK interface with 100 Mbit/s. Both connectors are designed as RJ45.
How many slots for interface modules are available?
The X20CP3686X has three slots for X20 interface modules.
