Bosch Rexroth MSK040C-0450-NN-M1-UP0-NNNN
Price on request
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Bosch Rexroth MSK030C-0900-NN-M1-UG1-NNNN identifies a permanent-magnet synchronous servo motor from the IndraDyn S range. The exact version carries material number R911308684 and combines the compact MSK030C size with the high-speed 0900 winding. Continuous torque is 0.8 Nm at 60 K winding overtemperature and 0.9 Nm at 100 K. The corresponding continuous currents are 1.5 A and 1.7 A. Up to 4.0 Nm maximum torque and 6.8 A maximum current are available briefly. Maximum speed is 9,000 min⁻¹. Position feedback is provided by a Hiperface multiturn absolute encoder with 128 signal periods. The variant has a plain shaft with shaft seal and a holding brake rated at 1.0 Nm with 24 V DC. Natural convection provides cooling, and the enclosure reaches IP65. The dimension drawing specifies an overall depth of 213 mm including the shaft for this braked version. With a housing width of 54 mm, maximum height including the connection area is 98.5 mm. Complete external dimensions are therefore 98.5 × 54 × 213 mm in height × width × depth order. Documented weight with holding brake is 2.1 kg. Mating connectors, cable bend and attached coupling parts are not included in these device dimensions. Exact identification is based on the complete type number, material number, winding, encoder, brake, shaft and connection version. Adjacent MSK030C versions can have different lengths or equipment despite a similar frame. The dimensions describe device space for installation, transport containers and storage positions; additional mounting clearances are outside the device dimensions.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Bosch Rexroth |
|---|---|
| Product series | IndraDyn S MSK |
| Manufacturer / order / identification number | MSK030C-0900-NN-M1-UG1-NNNN |
| Material number | R911308684 |
| Motor type | Permanent-magnet synchronous servo motor |
| Winding | 0900 |
| Continuous torque at 60 K | 0.8 Nm |
| Continuous current at 60 K | 1.5 A |
| Continuous torque at 100 K | 0.9 Nm |
| Continuous current at 100 K | 1.7 A |
| Maximum torque | 4.0 Nm |
| Maximum current | 6.8 A |
| Maximum speed | 9,000 min⁻¹ |
| Encoder | Multi-turn absolute encoder, Hiperface, 128 signal periods |
| Holding brake | 1.0 Nm at 24 V DC |
| Shaft | Plain, with shaft sealing ring |
| Cooling | Natural convection, self-cooled |
| Degree of protection | IP65 |
| Dimensions | 98.5 × 54 × 213 mm (H × W × D, including shaft) |
| Weight | 2.1 kg |
Related products
Go to shop
Bosch Rexroth MSK070C-0150-NN-S1-UG1-NNNN
€2,930.00
Bosch Rexroth MSK070C-0450-NN-S1-UG1-NNNN
€1,250.00
Bosch Rexroth MSM031C-0300-NN-M0-CH1
€680.00
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the dimensions of Bosch Rexroth MSK030C-0900-NN-M1-UG1-NNNN?
Complete external dimensions are 98.5 × 54 × 213 mm including the shaft.
How much does Bosch Rexroth MSK030C-0900-NN-M1-UG1-NNNN weigh?
Documented weight with holding brake is 2.1 kg.
