Control Techniques SP1203
Price on request
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
The DC input distinguishes Control Techniques SPMD1404 within the Unidrive-SPM power modules from versions with direct AC input. The module forms the inverter stage with AC drive output; the associated voltage class of the drive system is 380 to 480 V AC with a tolerance of ±10 %. For selection, the two duty types must be considered separately. In Heavy-Duty operation, the maximum continuous current is 290 A, with a typical motor power of 160 kW at 400 V or 250 HP at 460 V. In Normal-Duty operation, 350 A and a typical motor power of 200 kW at 400 V or 300 HP at 460 V are specified. The full current of 350 A requires that SPMD and SPMC are mounted separately, that each module receives its own airflow and that the ambient temperature does not exceed 35 °C. Otherwise the limit is 335 A. For an order with shipping from Germany to the United States and other international destinations, the identifier SPMD1404 is therefore decisive together with the intended duty type and the mounting arrangement. The cooling fans are supplied separately with 24 V DC; for this power module, the current demand of the fan supply is 5.0 A. The version includes dynamic braking control. The assigned minimum braking resistance is 3.8 Ω, and the specified braking power is 160 kW both instantaneously and as an average over 60 seconds. For the DC side, the fuse selection specifies 560 A in semiconductor class aR. The module identifier designates the individual power stage; additional suffixes for complete system configurations are to be distinguished from this identity.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Control Techniques |
|---|---|
| Product series | Unidrive SPM |
| Manufacturer/order/ident number | SPMD1404 |
| Device type | Modular inverter power module |
| Input and output | DC input, AC drive output |
| Voltage class of the drive system | 380–480 V AC ±10 % |
| Continuous current Normal Duty | 350 A with separate airflow and ≤35 °C; otherwise 335 A |
| Typical motor power Normal Duty | 200 kW at 400 V; 300 HP at 460 V |
| Continuous current Heavy Duty | 290 A |
| Typical motor power Heavy Duty | 160 kW at 400 V; 250 HP at 460 V |
| External fan supply | 24 V DC, 5.0 A |
| Braking control | Dynamic braking control |
| Minimum braking resistance | 3.8 Ω |
| Braking power | 160 kW instantaneous and as average over 60 s |
| DC fuse selection | 560 A, semiconductor class aR |
| Dimensions | approx. 300 × 1000 × 400 mm |
| Weight | approx. 60 kg |
Related products
Go to shop
Control Techniques SP1405
€840.00
Control Techniques SE1.5M
€640.00
Control Techniques SP0402
€980.00
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
Under which conditions do 350 A apply in Normal-Duty operation?
This current applies when SPMD and SPMC are mounted separately, with their own airflow per module and an ambient temperature of no more than 35 °C. Otherwise the limit is 335 A.
