Danfoss 130B2444
Price on request
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
As a frequency converter of the VLT AutomationDrive FC 302 series, the Danfoss 131F0430 handles speed control of electric drives. The specific configuration carries the model code FC-302P15KT5E20H1XGXXXXSXXXXAXBXCXXXXDX and is built for a three-phase line connection with 380 to 500 V AC. Its power ratings distinguish two overload classes: at high overload of 160 percent, the assigned power is 15 kW; at normal overload of 110 percent, it is 18.5 kW. These two operating ratings belong to the same device version and are stated separately. The unit sits in a chassis of frame size B3 with protection class IP20. An order for this B3 version is handled with order-related shipping from Germany to the United States and other international destinations. The electrical equipment includes an RFI filter of class A1/B or C1. A brake chopper is not included in this configuration, nor is an additional mains option. The cable entries are of the standard design. The printed circuit boards are uncoated. For local operation, a graphical control panel is part of the type configuration. Option positions A, B, C0, C1 and D are executed without additional option modules on this model; a C software option is not included either. The typical power loss assignment likewise distinguishes the two load classes: 379 W at high and 465 W at normal overload. Mechanically, the version without C options measures 165 mm in width, 399 mm in height and 249 mm in depth. The net weight is 11.27 kg. These dimensions refer to the configuration described here without additional A/B and C option modules.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Danfoss |
|---|---|
| Product series | VLT AutomationDrive FC 302 |
| Manufacturer/order/ident number | 131F0430 |
| Device type | Frequency converter |
| Power at high overload | 15 kW (HO, 160 %) |
| Power at normal overload | 18.5 kW (NO, 110 %) |
| Line voltage | 3-phase, 380 to 500 V AC |
| Protection class | IP20 / chassis |
| Frame size | B3 |
| RFI filter | RFI class A1/B (C1) |
| Brake chopper | Not included |
| Control panel | Graphical local control panel |
| PCB coating | Uncoated |
| Mains option | None |
| Cable entries | Standard |
| Power loss | HO: 379 W; NO: 465 W |
| Dimensions | 165 × 399 × 249 mm (W × H × D) |
| Weight | 11.27 kg |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
Is a brake chopper included?
The 131F0430 configuration is built without a brake chopper.
