Product description
The FANUC A06B-0314-B001 is an AC servo motor from the classic S series for controlled feed and positioning axes in CNC machine tools. The complete order number identifies the Model 5S version with three-phase supply, 126 V rated motor voltage and 5.8 A current. The series is documented with 133 Hz, eight poles and a maximum speed of 2000 U/min. Torque is 5.9 Nm and the associated power class is 0.9 kW. This makes the motor particularly suitable for compact axes, rotary tables and machine modules where a robust FANUC S-series servo architecture must remain in service. The A06B-0314-B001 version has a tapered shaft with feather key. Feedback is provided by a black incremental encoder with 2000 pulses and designation A860-0304-T111. Standard shaft seals protect the bearing and shaft area in a typical machine environment. Replacement work must therefore compare more than the model series and electrical ratings. Shaft design, feather key, encoder type, pulse count, connector version, mechanical mounting and assignment to the existing FANUC servo amplifier are equally important. The motor and encoder combination must match the existing controller, its feedback interface and the stored machine parameters. Similar A06B-0314 variants can differ significantly in encoder, brake, shaft or modification code. A neighbouring variant with a different suffix is therefore not an automatic replacement. Before commissioning, motor parameters, phase sequence, encoder connection and control settings for the specific CNC axis must be confirmed. The A06B-0314-B001 is a targeted replacement when the existing machine uses exactly this 5S configuration and its mechanical and electrical interfaces must remain unchanged.
Specifications
| Manufacturer | Fanuc |
|---|---|
| Product series | S series |
| Manufacturer / order / identification number | A06B-0314-B001 |
| Device type | AC servo motor |
| Motor frame size | Model 5S |
| Power class | 0.9 kW |
| Torque | 5.9 Nm |
| Rated motor voltage | 126 V |
| Current | 5.8 A |
| Phases | 3 |
| Frequency | 133 Hz |
| Maximum speed | 2000 U/min |
| Number of poles | 8 |
| Shaft | Tapered shaft with feather key |
| Feedback | Incremental encoder, 2000 pulses |
| Encoder designation | A860-0304-T111 |
Related products
Go to shop
Fanuc A06B-6079-H206
Price on request
Fanuc A06B-6058-H007
Price on request
Fanuc A06B-6058-H003
Price on request
Machine downtime?
Faster delivery
Is your machine down and do you require particularly fast delivery? Tell us directly. We will do everything possible to provide a quotation with the fastest available delivery and find a solution that matches your schedule.
Our highest priority is to keep your production processes running. Rely on our expertise and flexible service to minimise machine downtime effectively.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the rated data for the FANUC A06B-0314-B001?
The Model 5S servo motor operates on three phases with 126 V, 5.8 A and 133 Hz. It delivers 5.9 Nm torque and reaches a maximum of 2000 U/min.
What must be matched when replacing the A06B-0314-B001?
Check the complete order number, tapered keyed shaft, incremental 2000-pulse encoder A860-0304-T111, electrical ratings, connectors and the assigned FANUC servo amplifier.
