Fanuc A06B-0143-B077
€280.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
A stall torque of 12 Nm at 11 A is among the characteristic operating data of the FANUC A06B-0501-B756. As an AC servo motor of the Model 10, it performs the electromechanical conversion within a controlled drive axis. Its excitation is provided by permanent magnets; the electrical design is three-phase and eight-pole. The voltage is specified as 144 V and the speed as 2000 revolutions per minute. For the technical classification, the standstill values must be considered separately from the values for rotational motion: the 12 Nm and 11 A refer explicitly to the stationary motor. No additional power rating for operation at 2000 min⁻¹ is derived from them. The B756 version comprises a tapered shaft, a brake and a Pulsecoder A64. The Pulsecoder is the feedback element of the motor and supplies the encoder information for the controlled drive. Mechanical shaft connection and electrical feedback are therefore separate components of this motor version. For an order with shipping from Germany to the United States and other international destinations, the combination of Model 10, brake and A64-Pulsecoder is listed under the full identifier A06B-0501-B756. Insulation class F describes the thermal class of the winding insulation, while the specified ambient temperature is 40 °C. These two values have different reference quantities and are not treated as an identical temperature limit. For preliminary spatial planning, the housing dimensions are estimated at approx. 200 × 250 × 450 mm. For the weight, the reference is explicitly the shipping weight: the 60 lb correspond to a rounded gross weight of 27.22 kg. This weight includes the shipping reference and is therefore stated separately from a pure net motor weight.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | FANUC |
|---|---|
| Product series | Model 10 |
| Manufacturer/order/identification number | A06B-0501-B756 |
| Device type | AC servo motor |
| Stall torque | 12 Nm |
| Stall current | 11 A |
| Voltage | 144 V |
| Number of phases | 3 |
| Number of poles | 8 |
| Speed | 2000 min⁻¹ |
| Insulation class | F |
| Excitation | Permanent magnet |
| Ambient temperature | 40 °C |
| Encoder system | Pulsecoder A64 |
| Shaft type | Tapered |
| Brake | Present |
| Dimensions | approx. 200 × 250 × 450 mm |
| Gross weight | 27.22 kg |
