Fanuc A06B-0372-B175
Price on request
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Order number Fanuc A06B-6079-H106 identifies the single-axis Alpha servo amplifier module SVM1-130. Supply voltage is 283–325 V, while the motor output provides up to 230 V AC. Rated output current for the L axis is 52.2 A, and rated input power is 9.1 kW. The assembly uses a Type-A/B interface. Internal identifiers include unit specification A06B-6088-H230, wiring board A16B-2203-0454 with earlier identifier A16B-2202-0790, and circuit board A20B-2001-0932. Forced cooling with fan adapter A06B-6078-K002 is specified for certain motor and load combinations. This applies to designated high-load applications of the SVM1-130 size and is not a general feature of every installation. The enclosure is 380 mm high, 90 mm wide and 307 mm deep. Complete external dimensions are therefore 380 × 90 × 307 mm in height × width × depth order. The product-specific estimated device weight is approximately 6.5 kg. Order number, model, axis count, current class, voltage class, interface, board identifiers and cooling option distinguish the H106 version from adjacent Alpha amplifiers. Its tall, narrow enclosure supports vertical placement within the amplifier assembly and leaves space for the intended cooling-air path. Dimensions and weight refer to the individual module without fan adapter or shipping packaging.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Fanuc |
|---|---|
| Product series | FANUC Alpha |
| Manufacturer / order / identification number | A06B-6079-H106 |
| Device type | Servo amplifier module |
| Model | SVM1-130 |
| Number of axes | 1 axis |
| Interface | Type A/B |
| Input voltage | 283–325 V |
| Rated input power | 9.1 kW |
| Maximum output voltage | 230 V AC |
| Rated output current | 52.2 A on the L axis |
| Unit specification | A06B-6088-H230 |
| Wiring board | A16B-2203-0454 (A16B-2202-0790) |
| Printed circuit board | A20B-2001-0932 |
| Additional cooling | Fan adapter A06B-6078-K002 for documented high-load combinations |
| Dimensions | 380 × 90 × 307 mm (H × W × D) |
| Weight | approx. 6.5 kg |
