Alpha Power supply module PSM-37

Fanuc A06B-6087-H137

€1,150.00

excl. VAT

Product condition:
Used, removed from an installation

The item comes from dismantled equipment. We have not carried out an electrical inspection or a comprehensive operational check. Signs of age, use, installation or removal may be present. 14-day right of return in the event of a defect. See Terms and Conditions

  • In stock · Ships in approx. 1–2 business days · Express shipping on request
  • Urgent? Faster options such as direct or express shipping are often possible. Please state your required date when you request a quote or order.

Quantity: 1

Do you have any questions?

Personal service

We are happy to help with processing, shipping or individual quotations. Simply contact us:

Online and available Currently unavailable

International delivery

Available shipping options and net charges are calculated after the delivery country and postcode are entered at checkout. If no reliable rate is available, request an individual quotation.

Product description

Within the Alpha drive system, the Fanuc A06B-6087-H137 provides the DC voltage supply for servo and spindle amplifiers. The power supply module belongs to the PSM-37 version and connects a three-phase mains feed to a DC output. Its system role is therefore to supply the downstream drive modules, whose motor connections are located on the respective amplifiers. The functional design also includes power regeneration. The input operates with 200 to 230 V AC voltage at 50 or 60 Hz.

For an input voltage of 200 V, an input current of 150 A is stated; this reference condition belongs directly to this current value. On the output side, the module delivers 283 to 325 V DC voltage at an output power of 43 kW. The AC mains and the DC supply are therefore two separately described sides of the unit. For an order with shipping from Germany to the United States and other international destinations, PSM-37 designates the specific supply version within the Alpha module series.

Cooling comprises an internal and an external fan. The identifier of the external fan is A90L-0001-0335/B, that of the internal fan A90L-0001-0422. Diagnostics distinguish, among other things, fan standstill, increased heat sink temperature, dropped DC voltage and unusually high DC voltage. These states are detected via the module diagnostics. The front carries a status display as well as separately labelled plug connectors. The auxiliary output labelled CX2A and CX2B is marked with 24 V DC.

The mains terminals are marked L1, L2 and L3. The housing measures 150 mm in width, 380 mm in height and 307 mm in depth; the power connection area is located below the signal connections.

Specifications

Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.

Identification

Manufacturer Fanuc
Product series Alpha
Manufacturer/order/ident number A06B-6087-H137
Device type Power supply module PSM-37

Performance data

Input voltage 200–230 V AC
Input current 150 A at 200 V
Mains frequency 50/60 Hz
Output voltage 283–325 V DC
Output power 43 kW

Interfaces

Auxiliary output connection 24 V DC, CX2A/CX2B

Installation and environment

Cooling Internal and external fan

Dimensions and weight

Dimensions 150 × 380 × 307 mm
Weight (basis not specified) 10.7 kg

Further details

Function Supply of the drive system with power regeneration
Number of phases 3
