ABB 81AB03B-E
€790.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
The Fanuc R-2000iA/125L combines a six-axis articulated arm with a horizontal reach of 3,001 mm. The mechanical unit is configured for floor mounting. The maximum load capacity at the wrist is 125 kg. This wrist load must be distinguished from the weight of the robot itself and from the permissible load moments of the individual wrist axes. Axes J1, J2 and J3 each reach a maximum of 105 degrees per second. For J4 and J5, 170 degrees per second is specified for each axis; J6 reaches a maximum of 260 degrees per second. These different axis speeds describe the individual rotational movements of the articulated arm. Electric servo drives with AC servomotors provide the drive motion. The repeatability of this variant is ±0.2 mm. The permissible load moment at each of the wrist axes J4 and J5 is 588 Nm. For J6, 343 Nm is specified. These moment limits supplement the load capacity figure and describe wrist loading in greater detail. For the specific order, with shipping to the United States and other international destinations arranged individually, R-2000iA/125L identifies the floor-mounted 125-kg version with a long arm within this robot family. The stated ambient temperature range extends from 0 to 45 °C. The installation altitude is up to 1,000 m above sea level. The mechanical unit weighs 1,230 kg without the controller. Its spatial dimensions change with the positions of the six axes. The stated external dimensions of approx. 1.100 × 2,500 × 2,000 mm are therefore a rounded estimate for a compact, bent-arm position. They describe neither the full motion envelope nor the area required for a complete robot cell.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Fanuc |
|---|---|
| Product series | R-2000iA |
| Manufacturer / order / identification number | R-2000iA/125L |
| Device type | Articulated industrial robot |
| Controlled axes | 6 (J1–J6) |
| Mounting | Floor mounting |
| Wrist load capacity | 125 kg |
| Horizontal reach | 3,001 mm |
| Maximum axis speed J1–J3 | 105 °/s each |
| Maximum axis speed J4–J5 | 170 °/s each |
| Maximum axis speed J6 | 260 °/s |
| Repeatability | ±0.2 mm |
| Permissible load moment J4/J5 | 588 Nm each |
| Permissible load moment J6 | 343 Nm |
| Drive type | Electric servo drive with AC servomotors |
| Ambient temperature | 0–45 °C |
| Installation altitude | up to 1,000 m above sea level |
| Dimensions | approx. 1100 × 2500 × 2000 mm |
| Weight | 1,230 kg |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What does the weight figure refer to?
The 1,230 kg refers to the mechanical robot unit without the controller.
