Heidenhain 627032-02
€3,770.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Heidenhain 539878-03 identifies the 3 m variant of an armored adapter cable from the HEIDENHAIN accessory range. Manufacturer documentation lists base ID 539878-xx for an APK cable with a 10 mm outside diameter and six twisted conductor pairs, each with a cross-section of 2 × 0.19 mm². A 14-pin M12 coupling is fitted on the encoder side, while the subsequent-electronics side has a 15-pin D-sub connector with female contacts. Documented signal assignments include 1 Vpp and TTL. The complete identifier 539878-03 combines this construction with a cable length of 3.00 m; the same length is stated by the exact product record. For a flexible round cable, overall dimensions are expressed as length, outside diameter and outside diameter. They are therefore 3000 × 10 × 10 mm in length × diameter × diameter order. Connector projections are not included in this cable measurement because the manufacturer source does not provide separate overall dimensions for them. The existing weight of approx. 1.0 kg remains visibly marked as a conservative product-specific estimate. Full identification number, specified cable length, armored 10-millimetre construction and the combination of 14-pin M12 coupling and 15-pin D-sub connector jointly determine the exact variant. Conductor configuration and both connector ends also distinguish this version from HEIDENHAIN cables of similar length that use another diameter, pole count or signal assignment. Together these characteristics form the documented variant definition of this adapter cable.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Heidenhain |
|---|---|
| Product series | Connection cable |
| Manufacturer / order / identification number | 539878-03 |
| Mounting form | APK, armored version |
| Dimensions / cable length | 3.00 m |
| Dimensions / outside diameter | 10 mm |
| Signal conductor configuration | 6 × (2 × 0.19 mm²) |
| Encoder-side connection | M12 coupling, 14-pin |
| Electronics-side connection | D-sub connector, 15-pin, female contacts |
| Signal interface | 1 Vpp / TTL |
| Cable designation | APK 09 05 3.00 0SB014 3AB015-03 |
| Connection function | Adapter cable between encoder and subsequent electronics |
| Dimensions | 3000 × 10 × 10 mm (L × Ø × Ø, cable in protective armor) |
| Weight | approx. 1.0 kg |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the dimensions and weight of Heidenhain 539878-03?
The 3 m round cable in protective armor is specified as 3000 × 10 × 10 mm in length × diameter × diameter order. Product-specific estimated weight is approx. 1.0 kg.
Which connectors are fitted to Heidenhain 539878-03?
The cable connects a 14-pin M12 coupling to a 15-pin D-sub connector with female contacts.
