Product description
Heidenhain 557 679-10 identifies an absolute sealed LC 183 linear encoder for direct position measurement on linear machine axes. The ID number belongs to the version with a measuring length of 1040 mm. Its DIADUR glass scale contains an absolute track and an incremental track with a 20 µm grating period. Measuring step is 10 nm and accuracy grade is ±5.0 µm. Absolute position is output through the EnDat 2.2 synchronous serial interface, while an additional 1 Vpp incremental signal is available. Supply voltage ranges from 3.6 to 5.25 V and current consumption is below 300 mA. Electrical connection is provided by a 14-pin male flange connector. Maximum traversing speed is 180 m/min. The operating-temperature range is 0 to 50 °C. Protection is IP 53 when mounted according to the instructions and can reach IP 64 with sealing air. For this 1040 configuration, total length is ML + 121 mm, resulting in 1161 mm. Maximum cross-section across the housing and scanning unit is 85 × 37 mm. Cable and additional installation clearance are not included. The documented weight is 5.0 kg. ID number, measuring length, EnDat version and connection type together identify this LC 183 encoder. For installation planning, overall length is 1161 mm and maximum cross-section is 85 × 37 mm.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Heidenhain |
|---|---|
| Product series | LC 183 |
| Manufacturer/order/identification number | 557 679-10 |
| Device type | Absolute sealed linear encoder |
| Measuring length | 1040 mm |
| Accuracy | 5.0 µm |
| Grating period | 20,000 µm |
| Measuring step | 10 nm |
| Output signal | 1 Vpp |
| Data interface | EnDat 02 / EnDat 2.2 with incremental signal |
| Electrical connection | 14-pin male flange connector |
| Degree of protection | IP53 |
| Supply voltage | 3.6 to 5.25 V |
| Dimensions | 1161 × 85 × 37 mm (L × W × H, without cable) |
| Weight | 5.0 kg |
Related products
Go to shop
Heidenhain 662638-03
Price on request
Heidenhain 260 520 01
Price on request
Heidenhain 336963-23
Price on request
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the dimensions of Heidenhain 557 679-10?
The LC-183 encoder measures 1161 × 85 × 37 mm in length × width × height order, without cable.
How much does Heidenhain 557 679-10 weigh?
The ML 1040 version weighs approx. 5.0 kg without cable.
