8200 vector

Lenze E82EV551K4C200

Price on request

Availability is checked individually.

Product condition:
Used, removed from an installation

The item comes from dismantled equipment. We have not carried out an electrical inspection or a comprehensive operational check. Signs of age, use, installation or removal may be present. 14-day right of return in the event of a defect. See Terms and Conditions

  • The estimated delivery time will be confirmed for the specific order.
  • Urgent? Faster options such as direct or express shipping are often possible. Please state your required date when you request a quote or order.

Do you have any questions?

Personal service

We are happy to help with processing, shipping or individual quotations. Simply contact us:

Online and available Currently unavailable

International delivery

The individual quotation states the shipping method and costs for the item and destination.

Product description

The Lenze E82EV551K4C200 is an 8200 vector frequency inverter for variable-speed three-phase drives. Its complete type number identifies a built-in unit in the 400-V class with 0.55 kW typical motor power and an integrated EMC filter in the C200 version. Lenze specifies a three-phase mains connection from 320–550 V AC at 45–65 Hz. The DC link can alternatively be supplied with 450–775 V DC. At 400 V mains voltage, the rated mains current is 2.5 A without a mains choke or 2.0 A with a mains choke.

The documented output power is 1.3 kVA. Rated output current is 1.8 A at switching frequencies of 2, 4, and 8 kHz; the value at 16 kHz is 1.2 A. Output voltage follows the available mains voltage range, and the adjustable output frequency extends to 650 Hz. The 8200 vector system lists linear and quadratic V/f characteristics, vector control, and sensorless torque control. Available switching frequencies are 1, 2, 4, 8, and 16 kHz. For the 0.55-kW version, the manual states 50 W power loss at rated operation with 8 kHz.

A brake transistor is integrated, with an adjustable DC-link threshold of 790 V DC. Plug-in function modules provide the documented device functions and I/O configurations. The built-in enclosure measures 180 mm high, 60 mm wide, and 140 mm deep. The documented weight is 1.2 kg. The E82EV551K4C200 designation identifies the documented combination of power rating, voltage class, and filter version within the 8200 vector family.

Specifications

Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.

Identification

Manufacturer Lenze
Product series 8200 vector
Manufacturer / order / identification number E82EV551K4C200

Performance data

Typical motor power 0.55 kW
Mains voltage 320–550 V AC
Mains frequency 45–65 Hz
Alternative DC supply 450–775 V DC
Rated mains current 2.5 A without mains choke; 2.0 A with mains choke
Output power 1.3 kVA at 8 kHz
Rated output current 1.8 A at 2/4/8 kHz; 1.2 A at 16 kHz
Output frequency 0–650 Hz

Interfaces

Mains connection Three-phase

Dimensions and weight

Dimensions 180 × 60 × 140 mm (H × W × D)
Weight 1.2 kg

Further details

Device class Frequency inverter
Design Built-in unit
Switching frequencies 1, 2, 4, 8, or 16 kHz
Control modes V/f linear, V/f quadratic, vector control, sensorless torque control
EMC filter Integrated, C200 version
Brake transistor Integrated, adjustable threshold 790 V DC

Export data

Commodity code 85044095

General manufacturer information for the device class, not specific to order number E82EV551K4C200, as of 20/10/2026. Not a statement about the individual unit supplied; does not replace an export control review.

Lenze 8200 vector error codes

View all 34 error codes
Industrial production environment

Urgent requirement?

Shipping options

Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.

Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.

Contact us now!

Product safety

Manufacturer / EU responsible person

FAQ

Questions about E82EV551K4C200

Contact us
What electrical ratings apply to the Lenze E82EV551K4C200?

Lenze specifies 320–550 V AC at 45–65 Hz, 0.55 kW typical motor power, 1.3 kVA output power, and 1.8 A rated output current at 2, 4, or 8 kHz.

What are the dimensions of the Lenze E82EV551K4C200?

The Lenze system manual specifies 180 × 60 × 140 mm in height × width × depth order and a weight of 1.2 kg.

Ordering and service

What applies if an item develops a defect within 14 days?

For the condition categories “Used, removed from an installation” and “New, old stock”, the contractual 14-day right of return in the event of a defect applies. The defect must occur within 14 calendar days after delivery and be reported in text form within the same period.

In particular, the REHA tamper-evident seal must remain fully intact and our RMA approval is required before return. In an accepted case, we decide between replacement and refund. Details in Section 11 of the Terms.

Which shipping methods and delivery times are available?

The shipping method, shipping cost and estimated delivery time are confirmed for the specific order. Depending on the item, destination and urgency, we can check parcel, express or freight shipping as well as collection.

A delivery date is binding only if we expressly confirm it as binding.

Which payment terms apply?

The payment terms stated in the checkout or order confirmation apply. Depending on the order and customer, payment is made in advance or against invoice.

International deliveries and deliveries to new customers are generally made against advance payment unless we expressly confirm another payment arrangement.

Can I return an item ordered incorrectly or found incompatible?

No. There is no general B2B right of return, exchange, cancellation or withdrawal. Incorrect or duplicate orders and a lack of suitability or compatibility with the customer’s installation are not covered by the contractual 14-day right of return in the event of a defect. Details in Section 12 of the Terms.

Can I request individual pricing for several items?

You may request an individual quotation for several items or larger quantities. We then check availability and pricing for the specific requirement; there is no entitlement to a quantity discount. Open the quick enquiry.

Do you also purchase industrial spare parts?

Yes. You can offer us automation and drive components for purchase. Please provide complete type numbers, quantities, condition details and photographs where possible.

After review, we will tell you whether a purchase is possible and on which terms. Learn more about selling industrial stock.

Receive a quotation by email

Request availability

Use the form to request item-specific price, availability and estimated delivery information.
