Omron 3G3MX2-A4004-E
€570.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
For installation in a muting arrangement, the Omron F39-TGR-MCL-R-A is designed as a slim active transceiver unit with a pre-mounted bracket. The order number identifies only the active side of the active/passive system. The passive reflector F39-TGR-MCL-R-P is a separate component and is not included in this offer. Within the F39-TGR-MCL series, the unit adds optical muting detection to F3S-TGR-CL safety sensors. It uses a polarized retro-reflective principle with a red LED at 660 nm. The optical system uses the reflector as the passive counterpart to the active unit. The standard operating range is 0 to 4 m; the maximum operating range is 4.8 m. The electronics are supplied with 24 V DC and permit a deviation of ±20 %. Power consumption is no more than 5 W. The specified operating temperature range extends from −10 to +55 °C in an environment without condensation. For the electrical connection, the transceiver has a 5-pin M12 female connector. The enclosure has degree of protection IP65. The pre-mounted bracket and elongated construction belong to the offered active unit; this supplied version differs from the F39-TGR-MCL-R transceiver and reflector set. The spacing between the two muting beams is 250 mm. The active unit is 337.6 mm high, 38 mm wide and 39.6 mm deep. Its narrow 38-mm profile extends along the overall height, with the pre-mounted end brackets forming the mechanical termination. The net weight of F39-TGR-MCL-R-A is 1.36 kg. These mechanical values apply to the active transceiver unit rather than the complete set with passive reflector.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Omron |
|---|---|
| Product series | F39-TGR-MCL |
| Manufacturer/order/identification number | F39-TGR-MCL-R-A |
| Device type | Muting actuator / transceiver |
| System configuration | active/passive |
| Supplied version | active transceiver unit only, with pre-mounted bracket |
| Sensor series | Omron F3S-TGR-CL |
| Supply voltage | 24 V DC ±20 % |
| Power consumption | maximum 5 W |
| Operating temperature | −10 to +55 °C, without condensation |
| Connection | M12, 5-pin, female |
| Degree of protection | IP65 |
| Optical system | polarized retro-reflective system |
| Operating range | 0–4 m, maximum 4.8 m |
| Light source | red LED, 660 nm |
| Muting beam spacing | 250 mm |
| Dimensions | 337.6 × 38 × 39.6 mm (H × W × D) |
| Weight | 1.36 kg |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What does Omron F39-TGR-MCL-R-A include?
The order number identifies only the active transceiver unit of the active/passive muting system with a pre-mounted bracket.
Which mechanical data is specified?
The dimensions are 337.6 × 38 × 39.6 mm; the net weight is 1.36 kg.
