Product description
The Siemens 1HU3108-0AH01-Z is a permanent-magnet DC servo motor from the 1HU3 series. The basic version is documented with 160 V DC rated voltage, 2,000 min⁻¹ rated speed and 38 Nm torque. The electrical design operates with a DC armature circuit. Permanent-magnet excitation means that no separate field supply is required. The motor is naturally cooled and has protection class IP54. Siemens assigns the series to DC converters, including SINAMICS DCM. The complete mechanical envelope measures 660 mm in length, 190 mm in width and 190 mm in height. This results in outside dimensions of 660 × 190 × 190 mm. Documented weight is 88 kg. The square cross-sectional contour and overall length define the spatial classification of this motor size. The -Z version identifies order-dependent options and therefore remains part of the complete identity number. Specific optional equipment such as a brake, tachogenerator, connector position or shaft end is not defined by the open suffix alone. The complete designation 1HU3108-0AH01-Z is therefore decisive for product identity. The documented basic data describe the motor type through its electrical assignment, cooling method, protection class and outside size. Overall length, cross section and weight are available as fixed values for mechanical classification.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | 1HU3 |
| Manufacturer/order/identification number | 1HU3108-0AH01-Z |
| Device type | DC servo motor |
| Excitation type | Permanent-magnet excitation |
| Rated voltage | 160 V DC |
| Rated speed | 2,000 min⁻¹ |
| Torque | 38 Nm |
| Cooling method | Self-cooled |
| Protection rating | IP54 |
| Electrical system | DC armature circuit |
| Field excitation | Permanent magnets, no separate field supply |
| Converter application | For DC converters, including SINAMICS DCM |
| Dimensions | 660 × 190 × 190 mm (L × W × H) |
| Weight | 88 kg |
