Siemens 6ES7 412-2EK07-0AB0 is a CPU 412-2 PN central processing unit for the SIMATIC S7-400 automation system. It executes the user program, coordinates the connected modules and links the existing control to fieldbus and Industrial Ethernet communication. The Siemens data sheet specifies 1 MB of integrated RAM work memory, divided equally into 512 KB of program memory and 512 KB of data memory. The first communication interface, X1, supports MPI or PROFIBUS DP at up to 12 Mbit/s. The second interface, X5, is intended for Ethernet and PROFINET. Isochronous operation is supported via PROFIBUS DP or PROFINET. Power is supplied by the S7-400 system power supply and backplane bus. Typical current consumption from the 5-V-DC backplane bus is 1.1 A, with a maximum of 1.4 A; Siemens specifies typical power loss of 5.5 W. Load memory for programs and data can be expanded to 64 MB with a FLASH or RAM Memory Card. The CPU measures 25 x 290 x 219 mm and weighs approximately 750 g. The data sheet specifies hardware functional status 01, firmware V7.0 and STEP-7 V5.5 or higher with HSP 262 for engineering. A replacement therefore requires comparison of the MLFB and form factor as well as the firmware version, Memory Card, project version, MPI/DP addresses, PROFINET device name, IP configuration and connected devices. Other CPU-412, CPU-414 or older 6ES7-412 versions are not automatically interchangeable despite a similar front layout. Exact comparison protects existing machine programs, communication paths and startup conditions and supports planned recommissioning after a CPU failure.
| Manufacturer | Siemens |
|---|---|
| Product range | SIMATIC S7-400 |
| Manufacturer / order / identification number | 6ES7 412-2EK07-0AB0 |
| Device type | CPU 412-2 PN central processing unit |
| Work memory | 1 MB integrated RAM |
| Program memory | 512 KB integrated |
| Data memory | 512 KB integrated |
| Load memory | expandable to 64 MB with FLASH or RAM Memory Card |
| Interface X1 | MPI/PROFIBUS DP, up to 12 Mbit/s |
| Interface X5 | Ethernet/PROFINET |
| Isochronous operation | via PROFIBUS DP or PROFINET |
| Power supply | via SIMATIC-S7-400 system power supply |
| 5-V backplane bus current | 1.1 A typical; 1.4 A maximum |
| 24-V backplane bus current | 150 mA maximum per DP interface |
| Power loss | 5.5 W typical |
| Hardware functional status | 01 |
| Firmware version | V7.0 |
| Engineering | STEP 7 V5.5 or higher with HSP 262 |
| Dimensions | 25 x 290 x 219 mm |
| Weight | approx. 750 g |
Machine downtime?
Is your machine down and do you require particularly fast delivery? Tell us directly. We will do everything possible to provide a quotation with the fastest available delivery and find a solution that matches your schedule.
Our highest priority is to keep your production processes running. Rely on our expertise and flexible service to minimise machine downtime effectively.
Contact us now!Manufacturer / EU responsible person
The CPU 412-2 PN provides X1 for MPI or PROFIBUS DP at up to 12 Mbit/s and X5 for Ethernet or PROFINET.
The complete MLFB, hardware functional status, firmware, Memory Card, STEP 7 project, bus addresses, PROFINET device name, IP configuration and connected devices are decisive.
