Product description

The Siemens 6SE3214-0DA40 is a MICROMASTER Vector frequency inverter and is clearly listed in the Siemens manual as model MMV150/3. It is designed for a three-phase 380 to 500 V mains supply with a permissible deviation of ±10 percent. The corresponding motor rating is 1.5 kW or 2 hp. At 400 V, Siemens specifies a continuous output of 2.8 kVA. The rated output current is 3.7 A, the maximum continuous output current is 4.0 A and the maximum input current is 5.9 A. These figures provide a substantially stronger basis for selecting the correct replacement than the enclosure or product family alone. The inverter covers an output-frequency range of 0 to 650 Hz with a resolution of 0.01 Hz. Documented control modes include sensorless vector control, Flux Current Control and a voltage-frequency characteristic. Its overload capability is 200 percent for three seconds followed by 150 percent for 60 seconds, in each case relative to the rated current. Software-controlled fan cooling dissipates the heat generated during operation. The unit has an IP20 degree of protection, is specified for an operating temperature of 0 to 50 °C and supports the serial RS485 interface. Its compact enclosure measures 73 × 175 × 141 mm in width, height and depth, and the unit weighs 0.75 kg. Before replacement, the complete order number, mains-voltage range, power rating, current ratings, interface and enclosure size should be compared with the installed drive. This keeps the existing configuration within a MICROMASTER Vector installation traceable. The Siemens 6SE3214-0DA40 is intended for maintenance, spare-parts stockholding and the direct replacement of an identically configured MMV150/3. Shipping method and costs are stated in the quotation or order confirmation according to the destination, weight and required transit time.

Siemens 6SE3214-0DA40

Specifications

Manufacturer Siemens
Product series MICROMASTER Vector
Manufacturer / order / identification number 6SE3214-0DA40
Device designation MMV150/3
Device type Frequency inverter
Mains connection 3 AC 380–500 V ±10 %
Input frequency 47–63 Hz
Maximum input current 5.9 A
Motor rating 1.5 kW / 2 hp
Continuous output at 400 V 2.8 kVA
Rated output current 3.7 A
Maximum continuous output current 4.0 A
Output frequency 0–650 Hz
Frequency resolution 0.01 Hz
Overload capability 200 % for 3 s, followed by 150 % for 60 s
Control modes Sensorless vector control, FCC and V/f characteristic
Interface RS485
Degree of protection IP20 (NEMA 1)
Dimensions (W × H × D) 73 × 175 × 141 mm
Weight 0.75 kg
