Siemens 6SN1123-1AA00-0BA2
€1,000.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Siemens 6SN1130-1AA11-0BA0 is a single-axis feed module from the SIMODRIVE 611-A product range. Siemens documentation assigns the complete order number to an analogue VSA module with an enhanced interface. The exact version is documented for 12.5 A continuous current and 25 A short-time current. The speed setpoint is supplied through a ±10 V differential input. Motor feedback includes a tachometer and rotor-position encoder, while motor temperature is sensed by a PTC resistor. The module supports speed-controlled or current-controlled operation. A 24-V signal is specified for pulse enable. Measurement signals for actual speed and actual current are each described as ±10 V; for actual speed this range corresponds to motor rated speed, and for actual current it corresponds to the configured maximum current. Diagnostic monitoring covers I²t, heat-sink overtemperature and motor overtemperature. The power electronics are documented as a transistor pulse converter. These data identify the specific single-axis current and interface version within the SIMODRIVE-611-A family. Variant-specific mechanical data are available from UNIS Group. The data set specifies 50 mm, 480 mm and 270 mm for the three enclosure axes. In the normal module order of width × height × depth, complete external dimensions are 50 × 480 × 270 mm. Documented weight is 5.34 kg. Dimensions and weight refer to the individual module without shipping packaging. Manufacturer, product range, order number, device type, axis count, control, interface, current values, setpoint signal, motor feedback, temperature sensing, operating modes, measurement signals, diagnostics, power electronics, external dimensions and weight form the technical variant data set. The specification table concludes with Dimensions and Weight.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | SIMODRIVE 611-A |
| Manufacturer / order / identification number | 6SN1130-1AA11-0BA0 |
| Device type | Feed module |
| Number of axes | 1 axis |
| Control | Analog |
| Interface | Enhanced interface |
| Continuous current | 12.5 A |
| Short-time current | 25 A |
| Speed setpoint | Differential input ±10 V |
| Motor feedback | Tachometer and rotor position encoder |
| Motor temperature sensing | PTC resistor |
| Operating modes | Speed-controlled or current-controlled |
| Pulse enable | 24-V signal |
| Actual-speed measurement signal | ±10 V corresponds to motor rated speed |
| Actual-current measurement signal | ±10 V corresponds to Imax |
| Diagnostic monitoring | I²t, heat-sink and motor overtemperature |
| Power electronics | Transistor pulse converter |
| Dimensions | 50 × 480 × 270 mm (W × H × D) |
| Weight | 5.34 kg |
Related products
Go to shop
Siemens 6SN1118-0DH23-0AA1
€2,180.00
Siemens 6SN1118-0DM33-0AA1
€2,940.00
Siemens 6SN1123-1AA00-0HA1
€1,220.00
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the external dimensions of Siemens 6SN1130-1AA11-0BA0?
Complete external dimensions are 50 × 480 × 270 mm in width × height × depth order.
How much does Siemens 6SN1130-1AA11-0BA0 weigh?
The variant-specific product data specify a weight of 5.34 kg.
What applies if an item develops a defect within 14 days?
For the condition categories “Used, removed from an installation” and “New, old stock”, the contractual 14-day right of return in the event of a defect applies. The defect must occur within 14 calendar days after delivery and be reported in text form within the same period.
In particular, the REHA tamper-evident seal must remain fully intact and our RMA approval is required before return. In an accepted case, we decide between replacement and refund. Details in Section 11 of the Terms.
Which shipping methods and delivery times are available?
The shipping method, shipping cost and estimated delivery time are confirmed for the specific order. Depending on the item, destination and urgency, we can check parcel, express or freight shipping as well as collection.
A delivery date is binding only if we expressly confirm it as binding.
Which payment terms apply?
The payment terms stated in the checkout or order confirmation apply. Depending on the order and customer, payment is made in advance or against invoice.
International deliveries and deliveries to new customers are generally made against advance payment unless we expressly confirm another payment arrangement.
Can I return an item ordered incorrectly or found incompatible?
No. There is no general B2B right of return, exchange, cancellation or withdrawal. Incorrect or duplicate orders and a lack of suitability or compatibility with the customer’s installation are not covered by the contractual 14-day right of return in the event of a defect. Details in Section 12 of the Terms.
Can I request individual pricing for several items?
You may request an individual quotation for several items or larger quantities. We then check availability and pricing for the specific requirement; there is no entitlement to a quantity discount. Open the quick enquiry.
Do you also purchase industrial spare parts?
Yes. You can offer us automation and drive components for purchase. Please provide complete type numbers, quantities, condition details and photographs where possible.
After review, we will tell you whether a purchase is possible and on which terms. Learn more about selling industrial stock.
