Schneider Electric ATV930D75N4C
€3,680.00
Shipping information
Do you require same-day delivery or express shipping with a defined delivery time for this item?
Please contact us!
Product description
Schneider Electric MC-4/11/03/400 belongs to the PacDrive MC-4 family from ELAU and Schneider Electric and performs the servo-drive function for synchronized machine axes. The unique type number MC-4/11/03/400 identifies the 400-V version with 3 A continuous current; VDM01U30AA00 is listed as the product reference. The unit is therefore relevant for installed PacDrive M systems where axis control, Sercos communication and the existing control-cabinet layout must remain in use. The power input is designed for three-phase 380–480 V AC. Documented values include a mains frequency of 48–62 Hz, a rated current of 3 A and a peak current of 7.5 A. The control electronics receive a separate 24 V DC supply at 1 A and require approximately 12 W. At the motor output, the servo drive provides a three-phase voltage of 0–480 V AC at 3.0 A over a frequency range of 0–600 Hz. Heat is dissipated by natural convection. The installed mounting position must therefore continue to provide sufficient air circulation after replacement. In the PacDrive topology, MC-4 operates as a Sercos slave and is managed together with the connected servo motor in the controller configuration. Current rating alone is not enough for reliable replacement matching. Before installation, compare the type number, product reference, supply, output data, Sercos integration, motor assignment and installed firmware version. Other MC-4 current classes or customer-specific software versions may require a different configuration despite a similar enclosure. MC-4/11/03/400 is particularly suitable for maintenance, repair and spare-parts inventory for existing packaging, assembly and handling machines with a PacDrive M architecture. It enables the targeted replacement of a matching servo amplifier without a fundamental rebuild of the installed machine controller.
Specifications
| Manufacturer | Schneider Electric |
|---|---|
| Product range | PacDrive MC-4 |
| Manufacturer/order/identification number | MC-4/11/03/400 |
| Schneider product reference | VDM01U30AA00 |
| Additional part number | 13130245 |
| Device type | Servo drive / servo amplifier |
| Mains phases | 3-phase |
| Connection voltage | 380–480 V AC |
| Mains frequency | 48–62 Hz |
| Rated current | 3 A |
| Peak current | 7.5 A |
| Control voltage | 24 V DC |
| Control current | 1 A |
| Electronics power | approx. 12 W |
| Output voltage | 3-phase, 0–480 V AC |
| Output current | 3.0 A |
| Output frequency | 0–600 Hz |
| Communication role | Sercos slave in the PacDrive system |
| Cooling method | Natural convection |
Related products
Go to shop
Lenze E82MV752_4B001
Price on request
Lenze E82EV223_4B200
Price on request
Lenze E82EV552K2C200
€1,630.00
Machine downtime?
Faster delivery
Is your machine down and do you require particularly fast delivery? Tell us directly. We will do everything possible to provide a quotation with the fastest available delivery and find a solution that matches your schedule.
Our highest priority is to keep your production processes running. Rely on our expertise and flexible service to minimise machine downtime effectively.
Contact us now!Product safety
Manufacturer / EU responsible person
What is the function of Schneider Electric MC-4/11/03/400?
The unit is a PacDrive MC-4 servo drive for a three-phase motor axis and connects to the PacDrive controller as a Sercos slave.
What should be compared before replacing the MC-4?
Check the type number, VDM01U30AA00 product reference, 3-A current class, power supply, motor data, Sercos integration and installed firmware version.
