Modicon Premium Double-format PL7 processor module

Schneider Electric TSXP573623AM

Price on request

Availability is checked individually.

Product condition:
Used, removed from an installation

The item comes from dismantled equipment. We have not carried out an electrical inspection or a comprehensive operational check. Signs of age, use, installation or removal may be present. 14-day right of return in the event of a defect. See Terms and Conditions

  • The estimated delivery time will be confirmed for the specific order.
  • Urgent? Faster options such as direct or express shipping are often possible. Please state your required date when you request a quote or order.

Do you have any questions?

Personal service

We are happy to help with processing, shipping or individual quotations. Simply contact us:

Online and available Currently unavailable

International delivery

The individual quotation states the shipping method and costs for the item and destination.

Product description

Schneider Electric TSXP573623AM is a double-format PL7 processor module from the Modicon Premium automation platform. Schneider Electric assigns the CPU to the PL7 Junior/Pro software environment and the Transparent Ready concept. The documented rack configuration comprises up to 16 racks with four, six or eight slots, or eight racks with twelve slots. Processor capacity is 1.024 discrete and 128 analogue inputs and outputs. The specification also lists 32 application-specific channels and 15 process-control channels for up to 45 simple loops.

An Ethernet TCP/IP connection is integrated as an RJ45 port at 10/100 Mbit/s. Two non-isolated serial links use female mini-DIN connectors and operate at 19.2 or 115 kbit/s. Without a PCMCIA card, the processor has 64 Kwords of internal RAM for program and data. With a memory card, 80 Kwords of data are documented. PCMCIA cards also provide up to 384 Kwords of program memory and 2.688 Kwords of additional data storage. The application structure consists of one master task, one fast task and 64 event tasks.

The data sheet specifies an execution time of 0.12 µs for Boolean instructions without a PCMCIA card. Current consumption is 1,360 mA at 5 V DC. Local LEDs indicate processor operation, I/O or configuration faults, system faults, terminal activity, Ethernet status, reception and transmission. The degree of protection is IP20, and the documented operating range extends from 0 to 60 °C. The opened reference-specific dimensional source states 77 x 150 x 150 mm for the double-format module. The conservative product-specific weight estimate is approximately 0.8 kg. All data refers to the exact TSXP573623AM reference.

Specifications

Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.

Identification

Manufacturer Schneider Electric
Product series Modicon Premium
Manufacturer/order/identification number TSXP573623AM
Device type Double-format PL7 processor module
Serial interfaces 2 x mini-DIN, non-isolated, 19.2/115 kbit/s

Performance data

Current consumption 1,360 mA at 5 V DC

Interfaces

Application-specific channels 32
Process-control channels 15, up to 45 simple loops
Ethernet interface Ethernet TCP/IP, RJ45, 10/100 Mbit/s

Installation and environment

Degree of protection IP20

Dimensions and weight

Dimensions 77 x 150 x 150 mm (W x H x D)
Weight approx. 0.8 kg

Further details

Software environment PL7 Junior/Pro
Rack configuration 16 racks with 4/6/8 slots or 8 racks with 12 slots
Discrete I/O capacity 1.024 I/O
Analogue I/O capacity 128 I/O
Internal RAM 64 Kwords for program and data without PCMCIA card
PCMCIA memory up to 384 Kwords program and 2.688 Kwords additional data
Task structure 1 master task, 1 fast task, 64 event tasks
Boolean execution time 0.12 µs without PCMCIA card
