ABB 81AB03B-E
€790.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
The receiver side of the WS/WE 160 series combines an optical receiver unit with an electronic switching output. The SICK WE160-F440 bears the article number 6022742 and is one of the versions with a four-pin M8 connector. Its rectangular plastic housing measures 11 × 38 × 23 mm. The connection and optical axis are located on different sides of the housing; the electrical connector is physically separate from the receiving optics. In a through-beam photoelectric sensor, the transmitter and receiver face one another. The receiver evaluates the incoming light and derives the switching state from it. This optical principle uses a separate transmitter unit. The WE version denotes the receiver within the sensor pair. The PNP output of the WE160-F440 has a specified maximum output current of 0.1 A. The electrical supply range is 10 to 30 V DC. The sensitivity adjustment and a rotary switch for light-on or dark-on operation are located directly on the sensor. Position L denotes light-on operation, while D denotes dark-on operation. An orange LED indicates the output state; the green indicator shows signal strength or operating reserve. Switching indication and reception indication are therefore separate indicator elements on the receiver. For an order of the WE160-F440 receiver with an M8 connection, shipping to the United States and other international destinations is arranged for that specific order. The mechanical design includes a side mounting area with a hole and an elongated slot. In light-on operation, the output is active when light is received; dark-on operation uses the opposite switching state. Alongside the connection features, adjustable sensitivity and selectable switching mode are among the controls of this compact sensor design.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | SICK |
|---|---|
| Product series | WS/WE 160 |
| Manufacturer/order/identification number | WE160-F440 |
| Device type | Through-beam photoelectric sensor receiver |
| Supply voltage | 10–30 V DC |
| Output current | ≤ 0.1 A |
| Switching output | PNP |
| Switching function | Light-on/dark-on operation |
| Connection | M8 connector, 4-pin |
| Housing design | Rectangular |
| Housing material | Plastic |
| Sensitivity | Adjustable |
| Switching indicator | Orange LED |
| Signal strength indicator | Green LED |
| Dimensions | 11 × 38 × 23 mm |
| Weight | Approx. 0.02 kg |
