SIMATIC S5-135U/155U / U peripheral equipment Analogue input module 460

Siemens 6ES5460-4UA13

€330.00

excl. VAT

Product condition:
New, old stock

Unused goods from older stock. Original packaging, if present, may have been opened. Manufacturing date and packaging may vary; age- or storage-related marks are possible.

  • Available · Ships in approx. 1–2 business days
  • Urgent? Faster options such as direct or express shipping are often possible. Please state your required date when you request a quote or order.

Quantity: 1

Do you have any questions?

Personal service

We are happy to help with processing, shipping or individual quotations. Simply contact us:

Online and available Currently unavailable

International delivery

Available shipping options and net charges are calculated after the delivery country and postcode are entered at checkout. If no reliable rate is available, request an individual quotation.

Product description

The analogue signal path of Siemens 6ES5460-4UA13 comprises eight mutually galvanically isolated inputs. This module 460 belongs to the U peripheral equipment of the SIMATIC S5-135U and S5-155U systems. Plug-in measuring range modules determine whether voltages, currents or Pt100 resistance thermometers are acquired. Documented ranges include 12.5 mV, 50 mV and 500 mV as well as current ranges from 0 or 4 to 20 mA; further range modules cover the respective signal type. A relay multiplexer samples the eight channels either cyclically or individually.

At 50 Hz, the cycle across all inputs is 0.48 s and the integration time is 20 ms. An integration time of 16.67 ms is specified for 60 Hz. Wire-break monitoring can be configured for 50 mV, 500 mV and Pt100. Digital measured-value representation operates up to 2048 units in the rated range, while the overrange display extends to 4095 units. Shielded signal cables may be up to 200 m long; 50 m applies to ranges up to 50 mV.

Enable inputs and the external supply operate at 24 V. Internally, the module typically draws 0.13 A at 5 V and externally typically 0.15 A at 24 V. Maximum power loss is 3.5 W. It occupies one slot in the rack and uses a 42-pin front connector. The module measures 20 × 255 × 195 mm and weighs approximately 0.4 kg.

Specifications

Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.

Identification

Manufacturer Siemens
Product series SIMATIC S5-135U/155U / U peripheral equipment
Manufacturer/order/identification number 6ES5460-4UA13
Device type Analogue input module 460

Performance data

Maximum input voltage 18 V
Supply voltage 24 V DC external; 5 V DC internal
Current consumption typ. 0.13 A at 5 V internal; typ. 0.15 A at 24 V external
Power loss max. 3.5 W

Interfaces

Input channels 8 analogue inputs

Dimensions and weight

Cable length Shielded max. 200 m; 50 m for measuring ranges up to 50 mV
Dimensions 20 × 255 × 195 mm
Weight approx. 0.4 kg

Further details

Electrical isolation Inputs galvanically isolated
Measurement types Voltage, current and Pt100 depending on measuring range module
Measuring range modules Plug-in; required for each channel group
Sampling Cyclic or individual via relay multiplexer
Cycle time 0.48 s for 8 inputs at 50 Hz
Integration time 20 ms at 50 Hz; 16.67 ms at 60 Hz
Wire-break monitoring Configurable for 50 mV, 500 mV and Pt100

Product status and export data

Product status (manufacturer) End of life since 01/10/2022
Commodity code 85389091
Country of origin Germany
Export list number (AL) N
ECCN N

Manufacturer information for order number 6ES5460-4UA13, as of 20/10/2026. Not a statement about the individual unit supplied; does not replace an export control review.
