Product description
The Heidenhain 312 215-14 is an incremental built-in rotary encoder from the ERN 1387.001 product series. The exact identification number is associated with version ERN 1387.001-2048 and connection code 62S14-70. Heidenhain describes the ERN-1387 series as encoders with integral bearings for installation in servo motors. The scanning system provides 2,048 lines per revolution with a system accuracy of ±20 arc seconds. An analogue signal of approximately 1.1 Vpp is specified for this version; the cutoff frequency is at least 210 kHz. The encoder operates from a 5 V DC ±0.25 V supply. Its mechanical interface uses a tapered shaft with a functional diameter of 9.25 mm and a taper ratio of 1:10. The mechanically permissible speed is up to 15,000 min⁻¹. Typical starting torque is 0.01 Nm at 20 °C, while rotor moment of inertia is 2.6 × 10⁻⁶ kgm². Permissible axial movement of the drive shaft is ±0.5 mm. The family data specifies vibration resistance up to 300 m/s² in the range from 55 to 2,000 Hz and shock resistance up to 2,000 m/s² for 6 ms. The operating temperature range extends from -40 to +120 °C; protection rating IP40 according to EN 60529 is documented when mounted. Electrical connection is made through a straight, double-row 14-pin connector. For replacement matching, the complete identification number 312 215-14, the ERN-1387.001 version, 2,048 lines and the 62S14-70 connection must all correspond. Overall dimensions are approximately Ø58 × 50 mm and weight is approximately 0.3 kg.
Example image – The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
| Manufacturer | Heidenhain |
|---|---|
| Product series | ERN 1387.001 |
| Manufacturer/order/identification number | 312 215-14 |
| Device type | Incremental built-in rotary encoder with integral bearing |
| Line count | 2,048 lines per revolution |
| System accuracy | ±20 arc seconds |
| Output signal | approx. 1.1 Vpp |
| Cutoff frequency | At least 210 kHz |
| Supply voltage | 5 V DC ±0.25 V |
| Shaft | Tapered shaft Ø9.25 mm, taper 1:10 |
| Permissible speed | Up to 15,000 min⁻¹ |
| Starting torque | 0.01 Nm typical at 20 °C |
| Rotor moment of inertia | 2.6 × 10⁻⁶ kgm² |
| Permissible axial movement | ±0.5 mm |
| Vibration resistance | Up to 300 m/s² at 55–2,000 Hz |
| Shock resistance | Up to 2,000 m/s² for 6 ms |
| Operating temperature | -40 to +120 °C |
| Protection rating | IP40 according to EN 60529, when mounted |
| Dimensions | approx. Ø58 × 50 mm |
| Weight | approx. 0.3 kg |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
Which signal and resolution data applies to the Heidenhain 312 215-14?
Version ERN 1387.001-2048 provides 2,048 lines per revolution, a system accuracy of ±20 arc seconds and an analogue output signal of approximately 1.1 Vpp.
Which mechanical connection data is important when matching a replacement?
The documented data includes a tapered shaft with a 9.25 mm functional diameter and 1:10 taper, the 14-pin 62S14-70 connection and the complete identification number 312 215-14.
